1.5sqmm X 3 Core Submersible Cable
ZMW25.00
Silent Features
- Temperature range -40° to +90°
- Excellent Impact Resistant
- Excellent Weather Resistant
Technical Data
| Operating Temp : | -20°C to max.+90°C |
|---|---|
| Nominal voltage : | 1.1 KV |
| Test voltage : | 3.0 KV |
| Min. bending radius : | 6 x cable Diameter |
| Standard Packing: | Coils 100, 200, 300, 500, 1000m. |
|---|
Application
Ideal For Irrigation Pumps, Drinking Water Supply Pumps, and submersible Pump Motor Power Supply.
Core Colour
| As per IEC 60227 | Black, Light Blue, Brown, Yellow with Green Line/ Green with Yellow Line |
|---|---|
| As per IS 694: 2010 | Red, Yellow, Blue, Green / Black |
| Conductor | Insulation | Total Thickness of Double Sheath | Conductor Resistance at 20°C (max) | Current Rating at 40°C | |||
|---|---|---|---|---|---|---|---|
| Size of Cable | No. of Wire / Size of Wire | Thickness | Core OD | Thickness | Overall Size | ||
| Sq. mm. | Nos./mm | mm | mm | mm | mm | Ω/km | Amps. |
| 1.5 | 22/0.30 | 0.8 | 3.25 | 1.5 | 10.8 | 12.1 | 14 |
| 2.5 | 36/0.30 | 0.9 | 3.84 | 1.65 | 12.5 | 7.41 | 18 |
| 4.0 | 56/0.30 | 1.0 | 4.5 | 1.65 | 14.1 | 4.95 | 26 |
| 6.0 | 84/0.30 | 1.0 | 5.3 | 1.65 | 16.0 | 3.30 | 31 |
| 10.0 | 140/0.30 | 1.0 | 6.5 | 2.0 | 20.35 | 1.91 | 42 |
| 16.0 | 224/0.30 | 1.0 | 8.0 | 2.0 | 23.4 | 1.21 | 57 |
| 25.0 | 350/0.30 | 1.2 | 10.1 | 2.2 | 28.8 | 0.780 | 72 |
| 35.0 | 490/0.30 | 1.2 | 11.5 | 2.2 | 31.5 | 0.554 | 90 |
| 50.0 | 703/0.30 | 1.4 | 13.6 | 2.3 | 37.3 | 0.386 | 115 |
